5000 lumen and 8000 lumen dual system work lights are part of the Frosted Floodlight PRO. The series is designed with PC board to provide high quality diffuse and pleasant lighting. Coupled with a high-quality plastic housing, the lightweight design is ideal for a variety of indoor and outdoor areas.
Compared to the rest of the PRO series, the C+R Dual system is highly flexible, which means it is both a rechargeable floodlight and can be used as an AC work light, including a mains charger, with an integrated 5 meter meter.
The replaceable battery pack is another plus, it extends the usage time with a spare battery pack. A separate main charger for the battery pack is optional. The luminous flux is adjustable from 10% to 100%, saving energy and environmental protection.
| Art. number | S50PF-CS01H | S80PF-CS01H |
| Power source | 120 x SMD 2835 | 168 x SMD 2835 |
| Rated power (W) | 50 | 80 |
| Luminous flux(±10%) | 5000lm | 8000lm |
| Color temperature | 5700K | |
| Color rendering index | 80 | |
| Bean angle | 117° | 117° |
| Battery | 18650 11.1V 2600mAh | 21700 11.1V 4500mAh |
| Operating time(approx.) | 1.5H@5000lm | 1.5H@8000lm |
| Charging time(approx.) | 3.5H | 3.5H |
| Charging voltage DC (V) | 12.6V | 12.6V |
| Charging current (A) | 4A | 6.6A |
| Charging port | DC | DC |
| Charging input voltage (V) | 100- 240V AC 50/60Hz | |
| Charger included | Yes | Yes |
| Charger type | EU/GB with 5 meter H05RN-F 2x0.75mm² | |
| Switch function | on-off, turn switch button for 10%-100% | |
| Protection index | IP65 | |
| Impact resistance index | IK08 | |
| Service life | 25000 h | |
| Operating temperature | -10°C ~ 40°C | |
Store temperature: | -10°C ~ 50°C | |
| Art. number | S50PF-CS01H | S80PF-CS01H |
| Product type | Frosted flood light PRO | |
| Body casing | ABS+PC+TRP | |
| Length (mm) | 261 | |
| Width (mm) | 128 | |
| Height (mm) | 201 | |
| N.W. per lamp (g) | 1500 | 1568 |
| Accessory | lamp, manual | |
| Packaging | color box | |
| Carton quantity | 4 in one | |
Sample lead time: 7 days
Mass production lead time: 45-60 days
MOQ: 1000 pieces
Delivery: Sea/Air
Warranty period: 1 year after the goods arrive at the destination port
2 meter tripod, one and two ends
Q: Why choose C+R?
A: C+R means both rechargeable and rechargeable. It can be used as an emergency function in an environment where mains power cannot be found.
Q: Is C+R EPREL compliant?
A: Yes, we can provide the relevant test report.
Q: How to charge the battery pack?
A: You can use a single mains charger to charge the battery pack through the built-in DC charging port or through a work light when plugged into 220-240V~.
Q: Remove the battery pack, whether the working light can be turned on as AC function?
A: Yes, the only difference is the luminous lux.
