Product Certificate
Product Parameter
| Art. number |
P08SP-C01 |
| Power source |
16 x SMD (main) 1 x SMD(torch) |
| Rated power (W) |
6W(main) 1W(torch) |
| Luminous flux(±10%) |
100-600lm(main) 100lm(torch) |
| Color temperature |
5700K |
| Color rendering index |
80(main) 65(torch) |
| Bean angle |
116°(main) 42°(torch) |
| Battery |
18650 3.7V 2600mAh |
| Operating time(approx.) |
2.5-10H(main), 8H(torch) |
| Charging time(approx.) |
2.5H |
| Charging voltage DC (V) |
5V |
| Charging current (A) |
Max. 2A |
| Charging port |
TYPE-C |
| Charging input voltage (V) |
100 ~ 240V AC 50/60Hz |
| Charger included |
No |
| Charger type |
EU/GB |
| Switch function |
Torch-main-off, |
| Protection index |
IP54 |
| Impact resistance index |
IK08 |
| Service life |
25000 h |
| Operating temperature |
-10°C ~ 40°C |
|
Store temperature: |
-10°C ~ 50°C |
Poduct Details
| Art. number |
P08SP-C01 |
| Product type |
handlamp |
| Body casing |
ABS+Aluminum+TRP+PC |
| Length (mm) |
36 |
| Width (mm) |
43 |
| Height (mm) |
325 |
| N.W. per lamp (g) |
230g |
| Accessory |
Lamp, manual,1m USB -C cable |
| Packaging |
color box |
| Carton quantity |
25 in one |
Conditions
Sample leading time: 7 days
Mass production leading time: 45-60 days
MOQ: 1000 pieces
Delivery: by sea/air
Warranty: 1 year upon goods arrive destination port
Accesorry
N/A
FAQ
Q: Do you have COB version instead of SMD?
A: Yes, we have COB version with same design, item number is P08SP-C02.
Q: Can the dimming function be removed?
A: Yes, no problem.
Q: How long is the spindle lifetime?
A: Standard is 20000 times.
