Generation II construction frosted flood light PRO introduced a new rechargeable series, including 3000 lumen, 5000 lumen, 8000 lumen, 10000 lumen and 15000 lumen versions. The robust housing consists of ABS, ABS plus Aluminum, 4 corners with TPR protection, separate handle and bracket, the aim is to offer a professional working lights for craftsman.
This series introduces battery pack design, the goal is to facilitate the craftsmen to extend the use time by spare battery pack when needed. Press the bayonet switch to pull out the battery pack and push the another pack into its position.
Push the switch button to on/off the work site light, turn the switch button to change the different lumen levels. The USB output can supply power for other mobile devices. Battery indicator help you to follow the battery volume status and charging status.
| Art. number | S30PF-CS01 | S50PF-CS01 | S80PF-CS01 |
| Power source | 72 x SMD 2835 | 96 x SMD 2835 | 168 x SMD 2835 |
| Rated power (W) | 30 | 50 | 80 |
| Luminous flux(±10%) | 3000lm | 5000lm | 8000lm |
| Color temperature | 5700K | ||
| Color rendering index | 80 | ||
| Bean angle | 117° | 117° | 117° |
| Battery | 18650 11.1V 2600mAh | 21700 11.1V 4500mAh | 21700 11.1V 4500mAh |
| Operating time(approx.) | 2.5H@3000lm | 2.5H@5000lm | 2H@8000lm |
| Charging time(approx.) | 3.5H | 3.5H | 3.5H |
| Charging voltage DC (V) | 12.6V | 12.6V | 12.6V |
| Charging current (A) | 1.4A | 1.4A | 1.4A |
| Charging port | DC | DC | DC |
| Charging input voltage (V) | 100 ~ 240V AC 50/60Hz | ||
| Charger included | Yes | Yes | Yes |
| Charger type | EU/GB | ||
| Switch function | on-off, turn switch button for 10%-100% | ||
| Protection index | IP65 | ||
| Impact resistance index | IK08 | ||
| Service life | 25000 h | ||
| Operating temperature | -10°C ~ 40°C | ||
Store temperature: | -10°C ~ 50°C | ||
| Art. number | S30PF-CS01 | S50PF-CS01 | S80PF-CS01 |
| Product type | Frosted flood light PRO | ||
| Body casing | ABS+PC+TRP | ||
| Length (mm) | 261 | ||
| Width (mm) | 128 | ||
| Height (mm) | 201 | ||
| N.W. per lamp (g) | 1370 | 1370 | 1505 |
| Accessory | Lamp, manual | ||
| Packaging | color box | ||
| Carton quantity | 4 in one | ||
Sample leading time: 7 days
Mass production leading time: 45-60 days
MOQ: 1000 pieces
Delivery: by sea/air
Warranty: 1 year upon goods arrive destination port
2 meter tripod, one and two ends
Q: What is the maximum output the the USB socket?
A: it is 5V 2A, normally you can charge the mobile phone, bluetooth speaker. etc.
Q: How to judge the battery volume?
A: When you turn on the light, the indicator will light on. The more LEDs are on, the more power the battery has.
Q: How to charge the working light?
A: Charge the battery pack through the DC charging port by the supplementary mains adaptor.
